Place of Origin: | CHINA |
Brand Name: | AI |
Certification: | ISO |
Model Number: | AIC-943 |
Minimum Order Quantity: | 1 SET |
---|---|
Price: | Negotiable |
Packaging Details: | Hardboard |
Delivery Time: | 20days |
Payment Terms: | Western Union, T/T, L/C |
Supply Ability: | 20 sets per month |
Test Standard: | ASTM D943,GB/T12581 | Temperature Range: | Ambient~120℃±0.1℃ |
---|---|---|---|
Flow Range: | 0~200ML/H | Dimensions: | 630*710*930mm |
Power Supply: | 220V 50HZ | Weight: | 50KG |
Power Consumption: | 2400W | Warranty: | 1 Year |
Keyward: | Oxidation Characteristics Tester |
◆ Metal bath heating,safe and environment-friendly.
◆ Mic-computer temperature controller,digital display,accuracy ±0.1℃, PT100 sensor.
◆ Precise flow meter controls air flow.
◆ IT can do 6 tests simultaneously,every 3 samples for two groups.
◆ Working time is displayed digitally
◆ Glass tube as per standards
◆ Big power solid relay controlls temperature rising
◆ Over-temperature alarming.
Technical Specifications
Model | AIC-943 Inhibited Mineral Oils Oxidation Characteristics Tester |
Applicable standards | GB/T12581 ASTM D943 |
Heating method | electrical heating rod |
Temperature controlling range | ambient~120℃±0.1℃ |
Temperature controlling method | imported digital PID temperature controller |
Working units | 6 |
Timing method | digital timer |
Flow range | 0~200ML/H |
Total power consumption | 2400W |
Dimensions | 630*710*930mm |
Weight | 50KG |
Power supply | AC220V 50HZ |
