ISO4925 Stroke Simulation Measuring Equipment for Brake Fluids

ISO4925 Stroke Simulation Measuring Equipment for Brake Fluids

    • ISO4925 Stroke Simulation Measuring Equipment for Brake Fluids
    • ISO4925 Stroke Simulation Measuring Equipment for Brake Fluids
    • ISO4925 Stroke Simulation Measuring Equipment for Brake Fluids
  • ISO4925 Stroke Simulation Measuring Equipment for Brake Fluids

    Product Details:

    Place of Origin: CHINA
    Brand Name: AI
    Certification: ISO
    Model Number: F8095

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: Negotiable
    Packaging Details: Hardboard
    Delivery Time: 30 days
    Payment Terms: Western Union, T/T, L/C
    Supply Ability: 20 sets per month
    Contact Now
    Detailed Product Description
    Temperature Controlling Range: 20~150℃±2℃ Cooling Method: Compressor
    Power Supply: AC220V /50HZ Pressure Rang: 7Mpa±0.3 Mpa
    Stroke Count: 85,000 Cycles Stroke Rate: 1000 Cycles/h
    Test Standard: ISO4925 Warranty: 1 Year

    Summary

    This Stroke Simulation Measuring Equipment is suitable for evaluating the lubricating performance and material compatibility of brake fluid.

    Under specified test requirements, a total of 85,000 stroke tests are conducted to observe the changes in relevant materials.





    Main Features

    1. One cast iron brake master cylinder, with a cylinder diameter of 28.58mm to 28.65mm, and an aluminum alloy piston with a diameter of 28.52mm to 28.55mm.

    2. Three brake slave cylinders, with a cylinder diameter of 28.60mm to 28.66mm, and an aluminum alloy piston with a diameter of 28.52mm to 28.55mm.

    3. A set of specialized pump body adjustment installation plates.

    4. The main pipeline is made of uncoated steel pipe.

    5. A standard driving mechanism capable of generating a working pressure of 8 Mpa.

    6. Digital display of stroke rate with an adjustable device.

    7. Radiation-free heating system.

    8. Rubber cups that meet standard requirements.

    9. Microcomputer temperature controller with digital display, temperature control range: 20~150℃±2℃, PT100 temperature sensor for high precision.

    10. Pressure gauge displays working pressure, with a precision pressure regulating valve for adjustment, pressure: 7Mpa±0.3 Mpa.

    11. Digital timer with audible alarm.

    12. Fully enclosed compressor refrigeration, with gas circulation to reduce the temperature of the test chamber.

    13. Integrated structure for easy operation.





    Technical specifications

    1 Power supply AC 220 V±10%, 50 Hz
    2 Temperature control range 20~150℃±2℃
    3 Cooling method Compressor
    4 Temperature control method Digial PID temperature controller
    5 Timing method Digital timer
    6 Alarming method Buzzer
    7 Pressure range 7Mpa±0.3 Mpa
    8 Pressure Control Precision pressure regulating valve
    9 Pressure Display Precision pressure gauge
    10 Stroke Rate 1000 cycles/h
    11 Stroke Count 85,000 cycles



    ISO4925 Stroke Simulation Measuring Equipment for Brake Fluids
