Name: JFTOT Aviation Turbine Fuel Analysis Thermal Oxidation Stability Tester ASTM D3241
Brand: Advanced Instruments Co.,Ltd
SKU: OST-R4
Availability: InStock

Home Products Lubricating Oil and Lubricating Grease Analysis

JFTOT Aviation Turbine Fuel Analysis Thermal Oxidation Stability Tester ASTM D3241

Product Details:

Place of Origin:	CHINA
Brand Name:	AI
Certification:	ISO
Model Number:	OST-R4

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Price:	Negotiable
Packaging Details:	Hardboard
Delivery Time:	20 days
Payment Terms:	Western Union, T/T, L/C
Supply Ability:	20 sets per month

Contact Now

Detailed Product Description

Test Standard:	ASTM D3241 And GB/T9169	Test Method:	JFTOT
Test Temperature:	100℃~380℃±1℃	Pressure Difference:	0~340mmHg
Pressure System:	500psi±50psi	Ample Quantity:	600ml
Controlling Mode:	Computer	Warranty:	1 Year

ASTM D3241 Thermal Oxidation Stability Tester

Introduction:

It adopts multi advanced technology and make the test process automatic:

Operated by touch IPC,the working situation and interface can be observed at any time;
It has Self-diagnosis fault alarming and protection system;
Computer process system is designed as per ASTM D3241 which ensures the whole test procedure is correct and complete;
It has functions of data storage and printing test report;
It also has function of user-defined setting parameters ,which can satisfy requirements of special test for production and scientific research.
New model Falex heating tube is supplier by top brand Falex.Falex heating tube conform to ASTM D.02.Jo.

Specifications:

Test temperature	100℃~380℃±1℃
Pressure difference	0~340mmHg
Temperature range	ambient~150℃
Pressure system	500psi±50psi
Sample quantity	600ml
Flow of cool water	38±8L/H,Pressure of cool water:0.1~0.4Mpa
Measuring accuracy of pressure difference	0.1~0.4Mpa
Resolution of pressure difference displaying	0.1mmHg
Flow of fuel oil	20 drops/9±1 second
Display mode	touch screen
Controlling mode	Micro-computer
Power supply	AC220V 50Hz
Ambient temperature	10℃~40℃
Relative humidity	＜85%
Test standard	ASTM D3241
Test method	JFTOT
Test sample	Jet fuel,aviation turbine fuel

Photo of JFTOT Thermal Oxidation Stability Tester

JFTOT Aviation Turbine Fuel Analysis Thermal Oxidation Stability Tester ASTM D3241
