Place of Origin: | China |
Brand Name: | AI |
Certification: | ISO |
Model Number: | CM-08B |
Minimum Order Quantity: | 1 |
---|---|
Price: | Negotiable |
Packaging Details: | Carton |
Payment Terms: | L/C, D/A, Western Union, T/T |
Supply Ability: | 100 Sets/Month |
Test Standard: | ASTM D4308,ASTM D2624,ISO 6297 | Accuracy Of Conductivity Cell: | 1.00/M±5% |
---|---|---|---|
Accuracy: | 2%+2PS | Working Condition: | Temperature: 0~+40ºC |
Power Supply: | In-Built 6f22 Type 9V Battery | Main Unit: | 100*35mm |
Electrode: | φ14×140mm | Weight: | 0.5kg |
Size: | 100*35mm | Keyword: | Aviation Conductivity Meter |
Reference standards:
Technical specifications
1.Measuring range:
Model | Measuring range and resolution | Conductivity measuring value and accuracy | Main application |
CM-08B | 1~19999pS/m±1pS/m | 1~19999pS±(2%+2pS) | General oils,lubricating oil |
CM-08C | 0.1~1999.9nS/m±0.1nS/m | 0.1~1999.9nS±(2%+2d) | Alcohol, acetone, isopropanol |
(pS/m is unit of conductivity,equivalent to 'cu');
2.Structural constant and accuracy of conductivity cell:1.00/m±5%;
3.Reading mode:LCD digital display;
4.Power supply: in-built 6F22 type 9V battery,intermittently power supplying.(for exporting,the battery need to prepare by users);
5.Working condition: Temperature: 0~+40ºC; Relative humidity:≤85%
6.Structure characteristics:
Half-sealed structure
iaAT5 design
Small and portable
7.Overall dimension:
Main unit:φ100×35mm
Electrode:φ14×140mm
8.Weight:0.5KG
