ASTM D5453 Sulfur Content in UV Fluorescent Oil Analyzer

Home Products Petroleum Products Testing Equipment

ASTM D5453 Sulfur Content in UV Fluorescent Oil Analyzer

Product Details:

Place of Origin:	CHINA
Brand Name:	AI
Certification:	ISO
Model Number:	SCT

Payment & Shipping Terms:

Minimum Order Quantity:	1 SET
Price:	Negotiable
Packaging Details:	Hardboard
Delivery Time:	20 days
Payment Terms:	Western Union, T/T, L/C
Supply Ability:	20 sets per month

Contact Now

Detailed Product Description

Standards:	ASTM D5453	Test Method:	Ultraviolet Fluorescence
Temperature Controlling Range:	Ambient To 1150℃±1℃	Measuring Range:	5ppm ～5000ppm
Power Supply:	AC220V ± 10%, 50Hz	Total Power:	1500 W
Warranty:	1 Year	Sample Quantity:	5-20μL

ASTM D5453 Sulfur Content in UV Fluorescent Oil Analyzer

Introduction:

This instrument is used to determine the total sulfur content by UV fluorescence.It Improves the ability of anti-jamming and avoids the complicated operation of titration pool and factors of instability which used Coulometry. So the sensitivity of the instrument is greatly improved. The key components of the system adopt imported components to protect the detector light leakage and steam leakage and makes the machine has a reliable guarantee. Standards:SH/T 0689－2000, ASTM D 5453 -2006

Specifications:

Standard configuration	Printer＋Computer＋Main unit＋Liquid injector
Other optional parts	Solid sample injector, gas sample injector
Sample types	Solid, gas and liquid
Sample injection quantity	Solid:1-20mg; Liquid:5-20μL; Gas:1-5mL
Measuring range	5ppm ～5000ppm(High concentration should be diluted, Low concentration gas sample is up to 0.1ppm)
Temperature range	Ambient to 1150℃±1℃
Air supply requirements	High purity argon:above 99.9% ; High purity oxygen:above 99.9%
Power supply	AC220V±22V,50Hz±0.5Hz,1500 W
Dimension	Host:305(W)×460(D)×440(H)mm; Temp controller:550(W)×460(D)×440(H)mm
Net weight	Host:20kg, Temp controller:40kg
Test standard	ASTM D5453
Test method	Ultraviolet Fluorescence
