ASTM D3945 Shear Stability Test Apparatus Using a Diesel Injector Nozzle

ASTM D3945 Shear Stability Test Apparatus Using a Diesel Injector Nozzle

    • ASTM D3945 Shear Stability Test Apparatus Using a Diesel Injector Nozzle
    • ASTM D3945 Shear Stability Test Apparatus Using a Diesel Injector Nozzle
    • ASTM D3945 Shear Stability Test Apparatus Using a Diesel Injector Nozzle
    • ASTM D3945 Shear Stability Test Apparatus Using a Diesel Injector Nozzle
  • ASTM D3945 Shear Stability Test Apparatus Using a Diesel Injector Nozzle

    Product Details:

    Place of Origin: China
    Brand Name: AI
    Certification: ISO
    Model Number: AIC-3945

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiable
    Packaging Details: Hardboard
    Delivery Time: 20 days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 20 sets per month
    Contact Now
    Detailed Product Description
    Standards: ASTM D3945 Refrigeration: Air Compressor
    Temp.control Range: 35±0.2℃ Power Supply: AC220V/50HZ
    Total Power Consumption: 2.5KW Warranty: 1 Year
    Timing Method: Automatic Stroke Timer Flow Control: Liquid Flow Meter



    Shear Stability Test Apparatus Using a Diesel Injector Nozzle





    Introduction:

    This apparatus is new designed high technical product,which is combined with Germany technolgy.It is equivalent to all international brands,and all main components are imported from Germany directly.

    It's suitable to measure shear stability of polymer-containing fluids.The main unit is made up of Bosch Two pistons jet pump and atomization chamber with nozzle and its support.





    Features:

    1.Original imported Bosch jet pump,with nozzle and atomization chamber.
    2.This shear stability test apparatus adopts Bosch type axial nozzle injector,and there is a filter cartrigde on the nozzle support.
    3.The ball cooler has a case to transmit heat on the surface of case,
    4.Automatic stroke counter can cut off power automatically.
    5.The liquid storage tank is 250cm3,and there is a filling opening on the top.
    6.3 phase motor,power 1100W,rotation speed 925±25r/min.
    7.There is distributing plate in glass tube,and there are 3 way stop-cock at the cooling outlet.
    8.Micro-computer temperature controller,digital display,accuracy±1℃,PT100 probe
    9.Fully closed air compressor refrigeration,high cooling and low noise.
    10.Digital timer can record test time,and it has buzzer siren.
    11.There is discharging device on the top of jet pump.
    12.There is pressure control valve on pressure piping,and the display pressure is 17.5Mpa±0.35Mpa.






    Specifications:

    Applicable standards SH/T0103, ASTM D3945
    Timing method Automatic stroke timer
    Refrigeration method air compressor
    Temp.control range 35±0.2℃
    Flow control liquid flow meter
    Pressure control pressure adjusting valve,display by pressure gauge
    Total power consumption 2.5KW
    Powr supply 220 V/50 Hz



    ASTM D3945 Shear Stability Test Apparatus Using a Diesel Injector Nozzle
