Simulated Service Corrosion Test Apparatus for Engine Coolant by ASTM D2570

Home Products Coolant and Antifreeze Testing

Simulated Service Corrosion Test Apparatus for Engine Coolant by ASTM D2570

Product Details:

Place of Origin:	China
Brand Name:	AI
Certification:	ISO
Model Number:	AIC-2570

Payment & Shipping Terms:

Minimum Order Quantity:	1 set Simulated Service Corrosion Test Apparatus
Price:	Negotiable
Packaging Details:	Plywood case for one set Simulated Service Corrosion Test Apparatus
Delivery Time:	30 days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	20 sets per month

Contact Now

Detailed Product Description

Power Supply:	AC220V /50HZ	Test Standard:	ASTM D2570, SH/T0088
Total Power:	7KW	Flow Range:	0 ~ 95L / Min
Temp.control:	Omron	Flow Rate Control:	Flowmeter
Temperature Control Range:	Normal Temperature ~ 88 ºC	Timing:	Digital Timer
Color:	White	OEM Service:	Available

Introduction

The sample circulates for 1064h at 88 ºC and a certain flow rate in a closed system composed of a reservoir, a water pump, a radiator and rubber pipes. Its corrosion resistance is determined by the weight loss of typical metal test pieces used in the engine cooling system installed in the reservoir and the state surface of the internal surface of each component visually. The performance change of the sample is determined by analyzing the samples taken from the system regularly during the test cycle.

Characteristic

1. The Simulated Service Corrosion Test Apparatus is composed of operation and display, heating control, speed control, pressure control, flow control system and supporting components;
2. Motor: used for coolant circulation drive, linked with water pump;
3. Water pump: provide the circulation flow required by the standard;
4. Condenser: reduce the test pressure to simulate the automobile working condition;
5. Metal test piece: simulate metal corrosion working conditions;
6. Reservoir: provide catalytic effect;
7. Glass tube: observe the cyclic state of the sample

Technical specifications of ASTM D2570 Simulated Service Corrosion Test Apparatus

1	Applicable standards	ASTM D2570, SH/T0088
2	Environmental requirements	20 ºC ~ 25 ºC, humidity < 60%
3	Fuse	20A
4	Temperature control accuracy	± 3 ºC
5	Resolution (measurement)	0.1 ºC
6	Flow range	0 ~ 95L / min
7	Flow control accuracy	± 5%
8	Total power	7KW
9	Power supply	AC220V 50HZ
10	Temperature control range	normal temperature ~ 88 ºC
