    Product Details:

    Place of Origin: CHINA
    Brand Name: AI
    Certification: ISO
    Model Number: GWFI

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: Negotiable
    Packaging Details: Plywood case
    Delivery Time: 30 days
    Payment Terms: Western Union, T/T, L/C
    Contact Now
    Detailed Product Description
    Test Standard: IEC60695-2-10 ~ 13,UL 746A, IEC829, DIN695, VDE0471 Power Supply: AC220V ± 10% / 50Hz
    Weight: 30KG Temperature Range: 500 ~ 1000 ºC
    Timing Range: 0 To 99 Mins Color: White
    Warranty: 1 Year Keyword: Glow Wire Flammability Testing Apparatus

    Glow Wire Flammability Testing Apparatus

    Introduction:
    This Glow Wire Flammability Testing Apparatus is designed according to IEC60695-2-10: 2000 standard "glowing filament test method". It is applicable to electrical and electronic products, household appliances and materials fire hazard testing, simulate burning elements or overload resistance and the like heat or ignition source thermal stress caused by a short time.
    Glow Wire Flammability Testing Apparatus adopts chamber part and control part integrated design, convenient installation and debugging. Test chamber shell and important parts of stainless steel manufacturing, smoke, gas corrosion resistance; Automatic regulation control system adopts thyristor current, achieve the purpose of precise control temperature; Time, temperature digital display, easy observation records, stable and reliable use.

    Standard:
    IEC60695-2-10 ~ 13,UL 746A, IEC829, DIN695, VDE0471



    Technical Parameters:
    1. Temperature range: 500 ~ 1000 ºC, digital display adjustable,
    2. Temperature error: ± 10 ºC (500 ~ 750 ºC); ± 15 ºC (750 ~ 1000 ºC), temperature measuring instruments Accuracy ± 0.5 magnitude.
    3. Temperature sensors: Φ0.5K type armored thermocouple, thermocouple imports.
    4. Pressure applied to the specimen: 0.8N ~ 1.2N, and limit the indentation depth of at least 7mm.
    5. Timing range: 0 to 99 minutes 99 seconds adjustable,
    6. And having Shi burning time (Ta, generally according to standards set to 30), second holding burning time (Ti) and the flame goes out time (Te) of the timer;
    7. Time error: ± 1s.
    8. Ignited bedding layer: 10mm thick white pine wood, covered 12g / m2 ~ 30g / m2 standard tissue paper, from under the glow wire 200mm ± 5mm
    9. Instrument operation is simple, stable and reliable temperature measurementsystem,and automatic temperature compensation.
    10. Power supply: AC220V ± 10% / 50Hz. (Other power specifications can be customized.
    11.Dimension: 710*365*760mm
    12.Weight:30kg



    Basic information

    1 Power supply AC220V ± 10% / 50Hz(Other power specifications can be customized)
    2 Dimension 710*365*760mm
    3 Weight 30KG


    Photo of  Glow Wire Flammability Testing Apparatus

    Glow Wire Flammability Testing Apparatus IEC 60695-2-10,UL 746A,IEC829, DIN695, VDE0471
