Liquid Crystal Display Potentiometric Titrator

Liquid Crystal Display Potentiometric Titrator

    • Liquid Crystal Display Potentiometric Titrator
    • Liquid Crystal Display Potentiometric Titrator
    • Liquid Crystal Display Potentiometric Titrator
    • Liquid Crystal Display Potentiometric Titrator
  • Liquid Crystal Display Potentiometric Titrator

    Product Details:

    Place of Origin: CHINA
    Brand Name: AI
    Certification: ISO
    Model Number: ZDJ-4A

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: Negotiable
    Packaging Details: Carton
    Delivery Time: 20 days
    Payment Terms: Western Union, T/T, L/C
    Supply Ability: 20 sets per month
    Contact Now
    Detailed Product Description
    Keyword: Potential Titrator Measuring Items: PH,mV,temperature
    Dimension: 340×400×400mm3 Weight: 10KG
    Display: LCD Power Supply: AC (220±22)V,(50±1)Hz
    Warranty: 1 Year

    Liquid Crystal Display Potentiometric Titrator


    Functions

    uLCD display and English operation interface which can show measuring parameters and results.

    u The potential titrator has pre-titration, preset endpoint titration, blank titration or manual titration functions. It can form specific titration modes according to the user’s habit.

    uThere are several different titration modes with different sensors: acid base titration, redox titration,precipitation titration, complexometry titration and non-aqueous titration.

    uThe stirring system adopts PWM modulation technique and applies software to reduce the noise.

    u The titration equipment has RS-232 communication port and can be connected with TP-16 printer to print measuring data, titration curve and calculation results.

    uSpecific Rex titration software can be used to connect with PC and the results can be shown on the screen. Also, the titration modes can be edited and modified for remote control and calculation of several statistics.

    uThe titrator adopts the specific material which is against perchloric acid corrosion and can conduct several titration reactions.




    Technical Specifications
    No Item Specifications
    1 Measuring range

    pH:(0.0014.00)pH

    mV:(-18001800.0)mV
    temp:(-5.0105.0)°C

    2 Resolution

    pH:0.01pH

    mV:0.1mV

    temp:0.1°C

    3 Accuracy

    pH:±0.01pH±1 bit

    mV:±0.03FS

    Temp: ±0.3°C±1 bit

    4 Accuracy of titration tube volume

    10ml titration tube:±0.025ml

    20mltitration tube:±0.035ml

    5 Resolution of titration tube

    10ml titration tube:1/10000

    20mltitration tube:2/10000

    6 The speed of transfusion or fluid infusion (50±10)s(When the titration tube is full)
    7 Titration analysis of repeatability 0.2%
    8 Titration control sensitivity ±2 mV
    9 Stability (±0.3mV±1 bit)/3h
    10 Power AC (220±22)V,(50±1)Hz
    11 Dimension 340×400×400mm3
    12 Weight 10KG




    Photo of ZDJ-4A Liquid Crystal Display Potentiometric Titrator
    Liquid Crystal Display Potentiometric Titrator
